SPLACH PATRIOT
SPLACH PATRIOT
Aesthetic Truss Design with Practicality
The exquisite truss structure of PATRIOT is capable of affording more heavy and dynamic loads, giving this beast sufficient strength to carry out all the missions.
Remarkable Fat Tires
26X3.0 inch fat tires provide superior grip when riding all kinds of terrain, fitting for off-road adventures, weekend spins, and many other challenges you’ve probably never thought of.
1-Second Swappable Battery
Located in the center and integrated with the frame, 48V 20Ah lithium battery can easily be removed and re-installed, smaller and lasts longer.
Throttle & Pedal Assist
You can choose to use 1 or both of these 2 features at the same to give extra boost to the ride. Choose whatever mode you want at your discretion.
All About The Details
Front Suspension
Hydraulic lockout front suspension produces a firmer but smoother ride by dampening the roughness and absorbing shocks on the terrain.
Rear Suspension
The rear coil shock gives the suspensionsuppleness as well as robust performance, making obstacles a lot easier andsafer to cope with.
1500w Powerful Motor
The constant acceleration to 31 miles can be reached within 4.03 seconds. 85 Nm of torque powers through hills and loose terrain with ease.
Swappable Battery
Integrated and protected in the frame, 48V 20Ah battery is easy to remove for charging without extra tools.
Disc Brakes
Disc brakes generate a quick, clean stop for its stronger stopping power with the braking force much more consistent and reliable.
Rugged Fat Tires
26X3.0-inch fat tires are chosen for sturdy handling and stability. Instead of adopting 4-inch fat tires that areheavier, 3 inch-fat tires is just right for completing the missions of thefusion of a MTB and a road bike like PATRIOT.
Waterproof Wiring
Water-resistant wiring prolongs its lifespan and is ideal formaintenance.
Seat
Ergonomicdesign of the slightly wider seat with sculpted center cutaways is perfect fortrail, downhill and cross-country beatings.
Color LCD display
Riding data synchronized with your ridding patterns is presented on the intelligent colorful LCD.
Specifications
| SPLACH-Ebike | PATRIOT |
|---|---|
| Lithium Battery | 48V 20Ah Swappable Battery |
| Max Range | 26 Miles (42 KM) of Range Thumb Throttle, 27 Miles (44 KM) of Range Pedal Assist |
| Range Distance | 30-45 KM |
| Throttle | Thumb Throttle |
| Top Speed(Throttle Only) | 31 mph |
| Top Speed(Pedal Assist Only) | 20 mph |
| Riding Modes | Energy Saving Mode, Standard Mode and Sport Mode |
| Pedal Assist | Speed Sensor |
| Pedal Assist Level | Six Levels ( 0-5 ) |
| Charge Time | 4-6 Hours |
| Motor | Rear Hub Motor |
| Motor Power(Peak) | 1500 Watts |
| Controller | 48V 30A |
| Frame Material | Aluminium Alloy |
| Brakes | F/R Disc Brakes |
| Display | Colorful LCD |
| Lights | Front Light, Rear Reflector |
| Tire Type | 26*3.0 |
| Front Suspension | RPG Hydraulic Suspenison Fork with Adjustable Damping |
| Rear Suspension | Integrated Spring Airbag |
| Colors | Black Frame Blue Rear Swingarm / Black Frame Red Rear Swingarm |
| Startup Mode | Key Unlock |
| Vehicle Weight | 88 Lbs ( 40.0 Kg ) |
| Load Limit | 330 Lbs |
| Product Size | 6.3' x 2.3' x 3.7' ( 1910L x 700W x 1130H mm ) |
| Package Size | 5' x 0.9' x 2.9' （1530L x 280W x 880H mm） |
| Drive System | Chain Drive |
| Handlebar | Upright |
| Transmission | Shimano 7-Speed |
| Wheels | Spoke Wheel (Aluminium Alloy) |
